Rubber damper for inertia banc
Model TS-60/I
RUBBER DAMPER WITH INCREASED HEIGHT TO MANUFACTURE ACOUSTIC ACCESS FLOORS OR INERTIA BASES WITH BETTER RESULTS
EIt is a different and renewed, high-performance RUBBER damper. Manufactured with the most advanced technology and designed to eradicate all noise pollution by solid way.
THE ULTIMATE DAMPER FOR HEAVY FLOORS!
SENOR-TS-60/I
Patented
TS-60/I model does not change compared to TS-80, it is only slightly taller. Its trapezoidal design, with four indentations towards its interior forming an X-shaped figure, exponentially improves its internal elasticity, providing greater performance in the acoustic field and favouring perfect settling on the ground.
Fourth generation rubber damper recommended for raised floors under reinforced concrete slabs. Its new composition has a higher damping factor than standard polymers (polyurethane, polystyrene, EPDM, etc.)
There are 3 references differentiated by load range and colour:
* TS-60 V 150/25-I (Load range 30 – 150 kg)
* TS-60 A 280/25-I (Load range 140 – 280 kg)
* TS-60 R 400/25-I (Load range 250-400 kg)
✓ Recommended for application with concrete mortar thicker than 50 mm.
It is a different and renewed, high-performance RUBBER damper. Recommended for raised floors under reinforced concrete slabs.
Here you can download the installation manual
Product registered in the Spanish Patents and Trademark Office.
Its design favours a perfect settlement on the ground.
Its base incorporates 2 movement control stops
Quick and easy to install
Excellent results at impact noise
Load range: 30-150 kg
Load range: 140-280 kg
Load range:: 250-400 kg
Resonance Frequency: 7 – 15 Hz
Format de boite:
– SE-TS-60 V 150/25-I: 25 uds
– SE-TS-60 A 280/25-I: 25 uds
– SE-TS-60 R 400/25-I: 25 uds
Test Report Nº: B2022-LACUS-IN-176 A
Purpose: Airborne Soundproofing Test AND Impact Noise Insulation Test
Standards: UNE-EN ISO 10140-1:2022, 10140-2:2022 and 10140-3:2022
Laboratory: TECNALIA (Vitoria, SPAIN)
Date: 15 June 2022
Sample: CHOVA+SENOR CONCRETE ACOUSTIC FLOOR
Standardised Base Floor: Reinforced concrete slab
Standardised Base Thickness and Weight: 15 cm and 375 kg/m²
Total Acoustic Floor Thickness: 12.6 cm
Sample Description: Concrete acoustic flooring system comprising: SE-TS-80 V 150 dampers (SENOR) + SE-BEC-15×170 acoustic strip (SENOR)
+ 4 cm CHOVANAPA sound-absorbing material (CHOVA) + 16 mm MDF board + CHOVACUSTIC 65 FIELTEX multilayer component (CHOVA) + 6 cm reinforced concrete
Note: For the TS-60 product, the acoustic results obtained in this test are also valid, since both products share properties.
Result: An improvement of 13 dB in airborne sound compared to the base floor, which has a rating of 59 dB, resulting in a total soundproofing of 72 dB.
Result: Reduction of 37 dB in impact noise compared to the base floor, which has a rating of 76 dB, achieving a total soundproofing of 36 dB.
Laboratory measurement of airborne sound insulation and impact sound insulation improvement – WITH DAMPERS –
ACTUAL PHOTOS
