SENOR-PL-50
Patented
P.T. 200302961 (3-ES)
The most advanced rubber + steel damper for the suspension of acoustic ceilings for SIERRA profiles
Model PL-50
PL-50 is anultra-fast fastening that incorporates the most advanced locking harpoon of the moment (CLIP STOP). This type of acoustic hanger is designed to eradicate and attenuate the transmission of vibration produced by equipment with rotating and repetitive blows above 20 Hz.
There are two models depending on the load range and colour: Green and Blue
✓ PL-50 V (Load range from 8 to 30 kg)
✓ PL-50 A (Load range from 27 to 50 kg)
Installation video
THE RUBBER + STEEL ANTI-VIBRATION HANGER WITH ULTRA-QUICK FIXING TO SAW OR (TOOTH) STUD PROFILES.
Here you can download the installation manual
Product registered in the Spanish Patents and Trademarks Office
Fast fixation system
Easy and fast installation
With locking system to ensure the hanger to the ceiling channel
Load Range: 8-30 kg
Load Range: 27-50 kg
Resonance frequency: 7 – 15 Hz
Breaking point >= 200 kg
Box format:
– SE-PL-50 A/M6-25: 25 units
– SE-PL-50 V/M6-25: 25 units
– SE-PL-50 A/M6-100: 100 units
– SE-PL-50 V/M6-100: 100 units
* Available in M8
Sample project
SOUNDPROOFING TREATMENT FOR A CEILING IN PLACES WITH 80-90 DBA EMISSION
The PL-50 A is the product recommended for this project. You will find layout and total quantity in this report.
