SENOR – 47 MDS
Fire Resistance Test EI120 TECNALIA (Azpeitia – Guipúzcoa)
Utility Model
200201413/2
High-Performance Acoustic Ceiling with EI120 Fire Rating Airborne Noise (RA,con:77,3 dBA -DnTA > 75 dBA)
Model 47 MDS
This innovative hybrid acoustic hanger has been meticulously designed to offer an experience of tranquility and comfort in environments where intense activity can generate impact noise and disturbing vibrations. These situations are especially common in places where noise levels exceed 100 dBA during nighttime hours, such as live music venues, party rooms, theaters, cinemas, nightclubs, and wedding halls. In these spaces, daily interactions and ambient noise can cause discomfort both to clients enjoying the events and to citizens in the vicinity of the premises, highlighting the need for effective solutions for soundproofing. The model 47 MDS incorporates a patented system that includes a locking device considered the safest on the market, called **DS**. This component not only optimizes the performance of the acoustic hanger, but also significantly increases the mechanical safety of the system, preventing its potential collapse. Once this mechanism grips the metal framing, it holds it firmly without letting go, ensuring a robust and reliable integration. In fact, tests have shown that this model can be between two and three times more effective compared to traditional or similar damping systems, positioning itself as a superior choice for those looking to mitigate noise and maximize comfort in sound-filled environments. Its implementation translates into a more pleasant environment both for internal users and for those outside the establishment.
OPTIMIZE YOUR SPACES WITH EXCEPTIONAL ELASTICITY AND ACOUSTIC INSULATION IN A SINGLE COMPONENT!
SENOR HAS DONE IT AGAIN!
We are proud to announce that, through great effort and dedication, we have achieved a significant milestone in the sector. We are the first manufacturer of professional anti-vibration systems that has managed to not only develop but also offer advanced solutions for the creation of ACOUSTIC CEILINGS. These innovative ceilings possess an exceptional fire rating, featuring variants that guarantee safety and efficiency in critical situations: EI30, EI60, EI90, and EI120, each designed to withstand different levels of fire exposure and contribute to a safer environment in any building.
There are 4 different models depending on load range and colour: Grey, Green, Blue and Red
✓ 4715 G/MDS (Load range from 3 up to 15 kg)
✓ 4725 V/MDS (Load range from 15 up to 30 kg)
✓ 4750 A/MDS (Load range from 30 up to 50 kg)
✓ 4775 R/MDS (Load range from 45 up to 75 kg)
Installation video
THE MOST ADVANCED HYBRID ANTI-VIBRATION HANGER FOR VIBRATION PROTECTION WITH DIRECT FIXING TO TC47, F530 or MAESTRA 4717 TYPE CEILING CHANNEL PROFILES.
Here you can download the installation manual
Product registered in the Spanish Patents and Trademarks Office
Unique product with fire resistance test (EI-120)
Excellent soundproofing results thanks to the hybrid combination
Maximum safety thanks to the locking device
Easy and fast installation
Load Range: 3-15 kg
Load Range: 15-30 kg
Load Range: 30-50 kg
Load Range: 45-75 kg
Resonance frequency: 3 – 7 Hz
Breaking point: >= 200 kg
Box format:
– SE-4715 G/MDS-M6/50: 50 units
– SE-4725 V/MDS-M6/50: 50 units
– SE-4750 A/MDS-M6/50: 50 units
– SE-4775 R/MDS-M6/50: 50 units
* Available in M8
Test Report Nº: B2021-LACUS-IN-160 A
Purpose: Airborne Soundproofing Test AND Impact Noise Insulation Test
Standards: UNE-EN ISO 10140-1:2016, 10140-2:2011 and 10140-3:2011+A1:2015
Laboratory: TECNALIA (Vitoria, SPAIN)
Date: 25 November 2021
Sample: CHOVA+SENOR SUSPENDED ACOUSTIC CEILING – EI120
Standardised Base Floor: Reinforced concrete slab
Standardised Base Thickness and Weight: 15 cm and 375 kg/m²
Total Acoustic Ceiling Thickness: 30 cm
Sample Description: Suspended acoustic ceiling system comprising: SE-60M/DS dampers (SENOR) + SE-BEC-10×80 acoustic strip (SENOR) + TC-60 profiles (KNAUF) + SE-MONT-BICAPA-40 decoupling strip (SENOR) + 4 cm CHOVANAPA sound-absorbing material (CHOVA) + 25 mm Fireproof Plasterboard (KNAUF) + 4 mm VISCOLAM 65 acoustic membrane (CHOVA) + 25 mm Fireproof Plasterboard (KNAUF).
Note: The soundproofing results obtained in this test are also valid for the 47MDS product, as both products share the same properties.
Result: An improvement of 22 dB in airborne sound compared to the base floor, which has a rating of 57 dB, resulting in a total soundproofing of 78 dB.
Result: Reduction of 34 dB in impact noise compared to the base floor, which has a rating of 77 dB, achieving a total soundproofing of 42 dB.
Test report Nº: 080645-001
Objetive: Fire Resistance Test
Quality Standards: EN 1363-1:2012, EN 1364-2:2018 y EN 13501-2:2016
Laboratory: TECNALIA (Azpeitia – Guipúzcoa)
Date: 28 November 2019
Sample: SENOR+CHOVA EI120 SUSPENDED ACOUSTIC CEILING
Sample dimensions: 4 m length x 3 m width
Test duration: 180 minutes. An insulation failure occurs at minute 147 and an integrity failure occurs at minute 171.
Sample description: acoustic suspended ceiling consisting of SE-60M/DS dampers (SENOR) + SE-BEC-5×90 acoustic strip (SENOR) + TC-60 profiles + SE-F/RAPID 60 DS2 cross connector (SENOR) + SE-SRC threaded soles (SENOR) + 25 mm fireproof PYL (KNAUF) + 4 mm VISCOLAN 65 acoustic foil (CHOVA) + 25 mm fireproof PYL (KNAUF)
Field of direct application (changes or variants permitted):
– LENGTH: unlimited
– WIDTH: unlimited
– Further permitted variants are listed in the Classification Report.
Note: The soundproofing results obtained in this test are also valid for the 47MDS product, as both products share the same properties.
Result: Fire resistance classification: EI120 E120
Qualification fire resistance test according to the Standard EN 1364-2:2018
Fire resistance test according to the Standard EN 1364-2:2018
Construction detail
